China Basalt Fiber Surfacing Tissue Mat for Composite Reinforcement and Corrosion Resistance Products, Manufacturer

Basalt fiber surfacing tissue mat is a non-woven or composite functional material made of basalt fibers, usually in the form of a thin layer of gasket or face reinforcement. It combines the high temperature resistance, corrosion resistance and high strength characteristics of basalt fiber with lightweight, flexible or sealing properties, and is commonly used in high temperature protection, sealing, sound and heat insulation and other fields.

Send Inquiry

Product Description

Product Feature

Smooth Surface: Basalt fiber surfacing tissue mat creates a smooth and even surface finish, enhancing the aesthetics and appearance of composite products.
Protection: The surfacing tissue mat acts as a protective layer, providing resistance against abrasion, impact, and environmental factors, thereby extending the lifespan of the composite structure.
Compatibility: Basalt fiber surfacing tissue mat is compatible with various resin systems, including polyester, epoxy, and vinyl ester, allowing for versatility in composite manufacturing processes.
Chemical Resistance: Basalt fibers exhibit good chemical resistance, providing added protection against corrosive substances and chemical exposure.
Heat Resistance: Basalt fibers offer excellent heat resistance, ensuring that the surfacing tissue mat remains stable and intact even under high-temperature conditions.

Product Parameters

Filament Diameter (μm)	Areal Weight (g/m²)	Width (mm)	Organic Matter Content (%)	Moisture Content (%)	Resin Compatibility
11	30	1000	6-13	≤0.1	Epoxy, Polyester
11	40	1000	6-26	≤0.1	Epoxy, Polyester
11	50	1000	6-26	≤0.1	Epoxy, Polyester
11	100	1000	6-26	≤0.1	Epoxy, Polyester

Application

High temperature sealing gaskets:

Internal combustion engine exhaust pipe, turbocharger sealing. High temperature sealing of industrial pipe flanges (instead of asbestos gaskets).

Thermal barrier:

Battery pack thermal management (blocking heat transfer between cells). Aerospace equipment fire protection insulation.

Sound absorbing and noise reducing materials:

Automotive engine compartment, industrial equipment acoustic mats.

Reinforced composite top layer:

Used as a surface layer for composite panels to enhance impact and abrasion resistance.

Frequently Asked Questions

Q1: What are the primary benefits of using Basalt Fiber Surfacing Tissue Mat? A: It provides a smooth surface finish, enhances aesthetics, and acts as a protective layer against abrasion, impact, and environmental factors.

Q2: Which resin systems are compatible with this tissue mat? A: This mat is highly versatile and compatible with epoxy, polyester, and vinyl ester resin systems.

Q3: How does the mat perform in high-temperature environments? A: It offers excellent heat resistance, making it suitable for high-temperature sealing gaskets and thermal management in automotive and industrial applications.

Q4: Can it be used for chemical resistance? A: Yes, basalt fibers naturally exhibit good chemical resistance, providing protection against corrosive substances and chemical exposure.

Q5: What is the moisture and organic matter content of the mat? A: The moisture content is very low (≤0.1%), and the organic matter content typically ranges from 6% to 26% depending on the areal weight.

Q6: What typical applications involve this basalt fiber mat? A: Common applications include internal combustion engine exhaust sealing, battery pack thermal barriers, sound-absorbing mats for automotive engine compartments, and top layers for reinforced composite panels.
