Product Features
01
Smooth Surface: Basalt fiber surfacing tissue mat creates a smooth and even surface finish, enhancing the aesthetics and appearance of composite products.
02
Protection: The surfacing tissue mat acts as a protective layer, providing resistance against abrasion, impact, and environmental factors, thereby extending the lifespan of the composite structure.
03
Compatibility: Basalt fiber surfacing tissue mat is compatible with various resin systems, including polyester, epoxy, and vinyl ester, allowing for versatility in composite manufacturing processes.
04
Chemical Resistance: Basalt fibers exhibit good chemical resistance, providing added protection against corrosive substances and chemical exposure.
05
Heat Resistance: Basalt fibers offer excellent heat resistance, ensuring that the surfacing tissue mat remains stable and intact even under high-temperature conditions.
Product Parameters
| Filament Diameter (μm) |
Areal Weight (g/m²) |
Width (mm) |
Organic Matter Content (%) |
Moisture Content (%) |
Resin Compatibility |
| 11 |
30 |
1000 |
6-13 |
≤0.1 |
Epoxy, Polyester |
| 11 |
40 |
1000 |
6-26 |
≤0.1 |
Epoxy, Polyester |
| 11 |
50 |
1000 |
6-26 |
≤0.1 |
Epoxy, Polyester |
| 11 |
100 |
1000 |
6-26 |
≤0.1 |
Epoxy, Polyester |
Application
High temperature sealing gaskets:
Internal combustion engine exhaust pipe, turbocharger sealing.
High temperature sealing of industrial pipe flanges (instead of asbestos gaskets).
Thermal barrier:
Battery pack thermal management (blocking heat transfer between cells).
Aerospace equipment fire protection insulation.
Sound absorbing and noise reducing materials:
Automotive engine compartment, industrial equipment acoustic mats.
Reinforced composite top layer:
Used as a surface layer for composite panels to enhance impact and abrasion resistance.
Frequently Asked Questions (FAQ)
1. What are the primary benefits of using Basalt Fiber Surfacing Tissue?
It primarily provides a smooth, aesthetic surface finish, enhances impact and abrasion resistance, and offers excellent thermal and chemical protection for composite structures.
2. Can Basalt Fiber be used as a replacement for asbestos?
Yes, due to its excellent heat resistance and sealing properties, it is an ideal and safer alternative for asbestos gaskets in industrial pipe flanges and exhaust systems.
3. With which resin systems is this mat compatible?
The mat is highly versatile and compatible with common resin systems, including Epoxy, Polyester, and Vinyl Ester.
4. How does Basalt Fiber perform in high-temperature environments?
Basalt fiber is naturally heat-resistant and maintains its structural integrity and stability even under extreme temperature conditions typical of aerospace and automotive applications.
5. Is it suitable for battery thermal management?
Absolutely. Its thermal barrier properties make it effective for blocking heat transfer between cells in battery packs, enhancing overall safety.
6. Does the tissue mat improve the appearance of the final product?
Yes, it is specifically designed to create an even, smooth surface finish that significantly improves the aesthetic quality of composite components.
